Methacrylate Resins

Ultracure

Ultracure has been developed for the UV-cured pipe rehabilitation process, suitable for inversion lining repair. It can be used as a matrix material for in-situ or for pre-impregnated composites.

Order

Application focus

Ultracure has been developed for the UV-cured pipe rehabilitation process, suitable for inversion lining repair.

System type

Ultracure is a methacrylate-based, one-component system that includes the necessary UV initiator and is completely Styrene-free.

Viscosity

3000 ± 400 cP

Primary benefit

premium performance UV resin

Ultracure

Characterization
Composition
Properties
Technical Data

Order

Characterization

Built for UV rehabilitation workflows.

Ultracure has been developed for the UV-cured pipe rehabilitation process, suitable for inversion lining repair. It can be used as a matrix material for in-situ or for pre-impregnated composites.

Composition

Ultracure is a methacrylate-based, one-component system that includes the necessary UV initiator and is completely Styrene-free.

Components

Methacrylate-based blend with UV initiator One-component system, Styrene-free

Properties

tack-free
high chemical resistance (see TDS for test results)
high mechanical properties
adhere to concrete, steel, PVC

Technical Data

Technical data

Liquid component technical data

Density: 0.0397 ± 0.0036 lb/in³

Viscosity: 3000 ± 400 cP

Flash point: ~230 °F

Appearance, color: transparent, yellowish liquid

Hardened resin technical data

Young's modulus: > 435114 PSI

Tensile strength: > 8702 PSI

Elongation at break: > 3 %

Flexural modulus: > 391603 PSI

Flexural strength: > 11603 PSI

Compressive strength: > 21756 PSI

Shore-D hardness: > 85

Glass-transition temperature: 338 ± 18 °F

Heat deflection temperature (HDT): 257 ± 18 °F

Chemical resistance

To assess chemical resistance, we introduced a rating system from 1 to 5, with 5 indicating the highest resistance.

Normal petrol

Super petrol

CaCl2- saturated

Diesel

Acetic acid 10%

Acetic acid 20%

Ethanol

Oil

Phosphoric acid 10%

H2O2 30%

H2O2 5%

H2SO4 10%

H2SO4 20%

H2SO4 40%

HCl 10%

HCl 37%

HNO3 10%

HNO3 20%

HNO3 40%

IPA

MgCl2- saturated

NaCl 20%

NaOH 10%

NaOH 30%

NaOH 50%

Lactic acid 10%

Toluol

Methacrylate Resins

Ultracure

Configure Ultracure for your project and request ordering support directly from the Polinvent team.

Order Resin

Important product note

Product information on this page is provided for general informational purposes only. Performance depends on application, site, operating conditions, and compatibility with the rest of the system. If a Polinvent product is used together with third-party equipment, liners, resins, curing units, or other components, that combination requires written Polinvent approval. Otherwise, the customer must verify suitability and bears the integration and project-performance risk. Review the applicable SDS, TDS, and product manual where relevant. Binding specifications arise only from the Confirmed Order and the written technical documentation supplied by Polinvent.
