Methacrylate Resins

Shieldcure

Shieldcure is a fire-resistant (self-extinguishing) methacrylate resin developed for UV-cured pipe rehabilitation processes. The resin is suitable for inversion lining repair and can be used as a matrix material for in-situ or pre-impregnated composites. Recommended work temperature range is from -41 °F to +104 °F.

Order
Shieldcure

Application focus

Shieldcure is a fire-resistant (self-extinguishing) methacrylate resin developed for UV-cured pipe rehabilitation processes.

System type

Shieldcure resin is a methacrylate-based, one-component system that already contains the necessary UV initiator and is completely Styrene-free.

Viscosity

3000 ± 400 cP

Primary benefit

fire resistant UV formulation

Shieldcure
Order

Characterization

Built for UV rehabilitation workflows.

Shieldcure is a fire-resistant (self-extinguishing) methacrylate resin developed for UV-cured pipe rehabilitation processes. The resin is suitable for inversion lining repair and can be used as a matrix material for in-situ or pre-impregnated composites. Recommended work temperature range is from -41 °F to +104 °F.

Composition

Shieldcure resin is a methacrylate-based, one-component system that already contains the necessary UV initiator and is completely Styrene-free.

Components

  • Methacrylate-based one-component system with integrated UV initiator
  • No on-site component mixing required
  • Styrene-free formulation

Properties

  • tack-free
  • high chemical resistance (see TDS for test results)
  • high mechanical properties
  • Fire resistant (self-extinguishing).
  • adheres to concrete, steel and PVC

Technical Data

Technical data

Liquid component technical data

Density
0.0397 ± 0.0036 lb/in³
Viscosity (20 min-1)
3000 ± 400 cP
Flash point (closed space)
~230 °F
Appearance, color
transparent, yellowish liquid

Hardened resin technical data

Young's modulus
> 435114 PSI
Tensile strength
> 8702 PSI
Elongation at break
> 3 %
Flexural modulus
> 391603 PSI
Flexural strength
> 11603 PSI
Compressive strength
> 21756 PSI
Shore-D hardness
> 85
Glass-transition temperature
338 ± 18 °F
Heat deflection temperature (HDT)
257 ± 18 °F
Overall chemical resistance
outstanding

Chemical resistance

To assess chemical resistance, we introduced a rating system from 1 to 5, with 5 indicating the highest resistance.

Normal petrol

5

Super petrol

5

CaCl2- saturated

5

Diesel

5

Acetic acid 10%

5

Acetic acid 20%

4

Ethanol

5

Oil

5

Phosphoric acid 10%

5

H2O2 30%

3

H2O2 5%

5

H2SO4 10%

5

H2SO4 20%

5

H2SO4 40%

5

HCl 10%

5

HCl 37%

5

HNO3 10%

5

HNO3 20%

5

HNO3 40%

3

IPA

5

MgCl2- saturated

5

NaCl 20%

5

NaOH 10%

5

NaOH 30%

5

NaOH 50%

5

Lactic acid 10%

5

Toluol

5

Methacrylate Resins

Shieldcure

Configure Shieldcure for your project and request ordering support directly from the Polinvent team.

Shieldcure
Order Resin

Important product note

Product information on this page is provided for general informational purposes only. Performance depends on application, site, operating conditions, and compatibility with the rest of the system. If a Polinvent product is used together with third-party equipment, liners, resins, curing units, or other components, that combination requires written Polinvent approval. Otherwise, the customer must verify suitability and bears the integration and project-performance risk. Review the applicable SDS, TDS, and product manual where relevant. Binding specifications arise only from the Confirmed Order and the written technical documentation supplied by Polinvent.
