Methacrylate Resins

Methacure

Methacure has been developed for UV-cured pipe rehabilitation processes. The resin suits for relining and short-liner repair at the same time. The resin can be used as a matrix material for in-situ or for pre-impregnated composites.

Order

Application focus

UV-cured relining and short-liner rehabilitation

System type

One-component methacrylate with integrated UV initiator

Styrene content

Styrene-free formulation

Viscosity

3000 ± 400 mPas

Methacure

Characterization
Composition
Properties
Technical Data

Order

Characterization

Built for UV rehabilitation workflows.

Composition

Methacure resin is a methacrylate-based, one-component system that already contains the necessary UV initiator. The resin is completely Styrene-free. The viscosity of the resin can be modified with a thixotropic agent, the amount of which should be adjusted according to the specific application.

Components

Methacrylate-based blend with UV initiator One-component system, Styrene-free

Properties

good chemical resistance
good mechanical properties
good adhesion on vitrified-clay, concrete and steel

Technical Data

Technical data

Liquid component technical data

Density: 0.0397 ± 0.0036 lb/in³

Viscosity (20 min-1): 3000 ± 400 cP

Flash point (closed space): >212 °F

Appearance, color: transparent, yellowish liquid

Hardened resin technical data

Young's modulus: > 435114 PSI

Tensile strength: > 3626 PSI

Elongation at break: > 0.5 %

Flexural modulus: > 362595 PSI

Flexural strength: > 10153 PSI

Compressive strength: > 21756 PSI

Shore-D hardness: > 80

Glass-transition temperature: 203 ± 18 °F

Heat deflection temperature (HDT): 149 ± 9 °F

Overall chemical resistance: good

Chemical resistance

To assess chemical resistance, we introduced a rating system from 1 to 5, with 5 indicating the highest resistance.

Normal petrol

Super petrol

CaCl2- saturated

Diesel

Acetic acid 10%

Acetic acid 20%

Ethanol

Oil

Phosphoric acid 10%

H2O2 30%

H2O2 5%

H2SO4 10%

H2SO4 20%

H2SO4 40%

HCl 10%

HCl 37%

HNO3 10%

HNO3 20%

HNO3 40%

IPA

MgCl2- saturated

NaCl 20%

NaOH 10%

NaOH 30%

NaOH 50%

Lactic acid 10%

Toluol

Methacrylate Resins

Methacure

Configure Methacure for your project and request ordering support directly from the Polinvent team.

Order Resin

Important product note

Product information on this page is provided for general informational purposes only. Performance depends on application, site, operating conditions, and compatibility with the rest of the system. If a Polinvent product is used together with third-party equipment, liners, resins, curing units, or other components, that combination requires written Polinvent approval. Otherwise, the customer must verify suitability and bears the integration and project-performance risk. Review the applicable SDS, TDS, and product manual where relevant. Binding specifications arise only from the Confirmed Order and the written technical documentation supplied by Polinvent.
