Silicate Resins
Select the 3P silicate formulation that matches ambient temperature, cure speed, and field performance requirements.
Application focus
3PX Silicate Resin® is a two-component system developed for the rehabilitation of industrial...
System type
3PX Silicate Resin is made of two liquid components:
Viscosity
190 ± 30 cP
Primary benefit
extremely fast-setting
Potlife
4-6 min at 72 °F
Available formulations
7 types
3P silicate options. Select one type to update all specs below.
Characterization
3PX Silicate Resin® is a two-component system developed for the rehabilitation of industrial and communal wastewater facilities, water insulation of engineering structures. It results in a thick, high-strength, and chemical-resistant coating on technological structures. It's also suitable for use as a matrix material for glass fiber reinforced composites for various applications.
Composition
3PX Silicate Resin is made of two liquid components:
Properties
Ambient temperature at work
+50 °F - +104 °F
Mixing ratio
By mass: 2A : 3B
By volume: 1A : 2B
Application time
| Temperature | Pot life | Pressure release time |
|---|---|---|
| 50 °F | 10 - 12 min | 50 - 70 min |
| 59 °F | 8 - 10 min | 35 - 50 min |
| 68 °F | 5 - 7 min | 30 - 40 min |
| 77 °F | 4 - 6 min | 25 - 35 min |
Mixing guidance
Technical Data
MSZ EN 3251:2009
MSZ EN 3251:2009
MSZ EN 13892-2:2003
MSZ EN 13892-2:2003
MSZ EN 13892-8:2003
MSZ EN 12617-4-2002
MSZ EN 9640-8:1988
MSZ EN 12808-5:2009
To assess chemical resistance, we introduced a rating system from 1 to 5, with 5 indicating the highest resistance.
Normal petrol
1
Super petrol
5
CaCl2- saturated
5
Diesel
5
Acetic acid 10%
5
Acetic acid 20%
5
Ethanol
1
Oil
5
Phosphoric acid 10%
5
H2O2 30%
5
H2O2 5%
5
H2SO4 10%
5
H2SO4 20%
4
H2SO4 40%
5
HCl 10%
5
HCl 37%
4
HNO3 10%
5
HNO3 20%
4
HNO3 40%
1
IPA
4
MgCl2- saturated
5
NaCl 20%
5
NaOH 10%
5
NaOH 30%
5
NaOH 50%
5
Lactic acid 10%
5
Toluol
4
1
Mechanical properties changed significantly (color may change).
The coating is not suitable for storing the test chemical.
2
Mechanical properties changed considerably (color may change).
The coating may suit storage for less than 1 week.
3
Mechanical properties changed moderately (color may change).
The coating may suit storage for less than 1 month.
4
Mechanical properties changed slightly (color may change).
The coating may suit storage for 1 to 2 months.
5
Mechanical properties remained unchanged (color may change).
The coating is suitable for permanent storage of the test chemical.
Assessment guide based on one month of soaking at 77 °F.
The specimen surface was exposed to permanent contact with the test chemical.
Important product note
Product information on this page is provided for general informational purposes only. Performance depends on application, site, operating conditions, and compatibility with the rest of the system. If a Polinvent product is used together with third-party equipment, liners, resins, curing units, or other components, that combination requires written Polinvent approval. Otherwise, the customer must verify suitability and bears the integration and project-performance risk. Review the applicable SDS, TDS, and product manual where relevant. Binding specifications arise only from the Confirmed Order and the written technical documentation supplied by Polinvent.
